Map Sub-Tier Supplier Dependencies Before Adding a Vendor

Before counting two suppliers as independent cover, trace the critical material, special process, tooling and production site behind each one. Record shared dependencies, unknowns and the time needed to qualify and receive usable supply through an alternative route.

A purchasing team approves a second machined-part supplier. Both suppliers send the same operation to one heat-treatment facility. Two purchase accounts now exist, but the critical process still has one point of failure. A sub-tier map lets the purchase head and engineering team test whether the proposed backup changes that exposure.

Start from one critical requirement

Choose a component whose absence stops an important job and define the revision, material, special processes and approved acceptance route. Bring the BOM, direct supplier list, known outside-process records, tool ownership details and evidence of approved alternatives. Ask suppliers for the specific dependency information needed for continuity; do not assume a different company name means a different physical route.

NIST’s supply-chain risk guidance recommends mapping dependencies and considering the time required for alternate supply to start shipping. The worksheet below is our application to a manufacturing component, not a supplier rating or a claim about a named vendor.

Keep unknown evidence separate from a negative answer

“Supplier did not disclose the mill” means the source is unknown. It does not mean the supplier has no control or is unreliable. Record the evidence date, contact, scope and confidence of each dependency. An outdated email about a different part cannot establish today’s route for the critical revision.

Prioritise gaps by the production consequence and the work needed to resolve them. Engineering owns process equivalence and technical qualification. Quality owns the applicable acceptance evidence. Purchasing owns supplier confirmation and commercial readiness. Planning identifies which orders remain exposed while those actions are unfinished.

Calculate the recovery sequence honestly

Illustrative recovery plan: tooling preparation takes 12 days, a required qualification step takes 8 days after the tool is ready, production takes 6 days after approval, and transport takes 2 days. If those steps are sequential, the earliest complete route is 12 + 8 + 6 + 2 = 28 days. A seven-day stock cover leaves 21 days of uncovered time under those assumptions.

If tasks can overlap, draw their dependencies and recalculate the critical path; do not add every duration blindly. Include approval and usable receipt, not only the supplier’s machining time. A proposed 28-day route is a planning scenario until the owners confirm its inputs. Keep the date and assumptions with the number.

Choose a specific mitigation: qualify a different process route, secure tool access, investigate a second material source or revise the continuity plan. Buying more from supplier B does not remove the shared facility H exposure in the example.

Maintain the map with the supplier records

Our purchasing workflow holds vendor information and supporting records. With Optiwise custom modules and attachment-supported forms, you can configure a dependency register linked to the relevant party and component. Label unconfirmed relationships explicitly; a connected record is only as current as its evidence.

Accept the first map when each critical dependency is confirmed or assigned to an owner, the alternative route has a stated approval status, and recovery timing follows the actual sequence. Revisit it after a site, process, tool or material-source change.

Supplier-map questions

Does a shared sub-tier always disqualify the second supplier?

No. It means the two suppliers do not independently cover that dependency. Decide the mitigation from the consequence and available alternatives.

Can we call a supplier a backup before qualification?

Record it as a candidate route until the required technical, quality and commercial conditions are complete. Keep sourcing potential separate from usable supply.
